VARIANTS

PART NO. ARTICLE LAN OP. TEMPERATURE USE CASE
HCC01-0000-80-0 COMh-ccAS W680 2x I226 0 °C – +60 °C PC Client
HCC01-0000-70-0 COMh-ccAS Q670 2x I226 0 °C – +60 °C PC Client
HCC01-0000-10-0 COMh-ccAS H610 2x I226 0 °C – +60 °C PC Client
HCC02-0000-8E-0 COMh-ccAS R680E 1x I226; 1x GPY215 0 °C – +60 °C Embedded
HCC02-0000-7E-0 COMh-ccAS Q670E 2x I226 0 °C – +60 °C Embedded
HCC02-0000-1E-0 COMh-ccAS H610E 2x I226 0 °C – +60 °C Embedded
Please contact tech support for custom UEFI firmware.

CARRIER

ARTICLE PART NO. DESCRIPTION
COM-HPC CLIENT CARRIER 10MM HCT01-0000-10-0 COM-HPC Client Carrier with 10mm Connector Height

COOLING

ARTICLE PART NO. DESCRIPTION
COMh-ccAS HEAT SPREADER HCC0A-0000-99-0 Standard COM-HPC Heat Spreader for COMh-ccAS
COMh-ccAS X-BRACKET HCC0A-0000-99-1 X-Shape Bracket for Standard Motherboard Cooler
COMh-ccAS PCH COOLER HCC0A-0000-99-2 PCH Cooler for COMh-ccAS
COMh-ccAS COOLING KIT 65W HCC0A-0000-99-3 Motherboard CPU Cooler + X-Bracket + PCH Cooler for up to 65 W CPUs
COMh-ccAS COOLER MOUNTING JACKET HCC0A-0000-99-4 Needs to be used instead of X-Bracket, when 4th memory module is in use

MEMORY

PART NO. MIN. SPEC. SIZE ECC/NON-ECC OP. TEMPERATURE
97040-0848-CCAS DDR5-4800 8 GByte No ECC 0 °C to +60 °C
97040-1648-CCAS DDR5-4800 16 GByte No ECC 0 °C to +60 °C
97040-3248-CCAS DDR5-4800 32 GByte No ECC 0 °C to +60 °C
97050-0848-CCAS DDR5-4800 8 GByte ECC 0 °C to +60 °C
97050-1648-CCAS DDR5-4800 16 GByte ECC 0 °C to +60 °C
97050-3248-CCAS DDR5-4800 32 GByte ECC 0 °C to +60 °C
