FEATURES
| Compliance | SMARC – Smart Mobile Architecture by SGET – small size |
| Dimensions (H x W x D) | 82mm x 50mm |
| CPU | Intel® Atom™ E3845, 4C, 1.91GHz, 10W TDP Intel® Atom™ E3827, 2C, 1.75GHz, 8W TDP Intel® Atom™ E3826, 2C, 1.46GHz, 7W TDP Intel® Atom™ E3825, 2C, 1.33GHz, 6W TDP Intel® Atom™ E3815, 1C, 1.46GHz, 5W TDP |
| Main Memory | up to 8GB DDR3L-1333 memory down (ECC optional) |
| Graphics Controller | Intel® HD Graphics (Gen7) |
| Ethernet Controller | Intel® i210IT |
| Ethernet | 10/100/1000 MBit Ethernet |
| SATA | 1x SATA 3Gb/s |
| Flash Onboard | 2-64GB eMMC |
| PCI Express / PCI support | 3x PCIe x1 |
| Panel signal | LVDS Single Channel 18/24 bit or eDP HDMI or DP |
| USB | 3x USB 2.0 1x USB 3.0 (via AFB) |
| Serial | 1x RX/TX (Ser0) 2x UART (Ser1/3) |
| Interface | HD Audio and I2S, 5x I2C, 2x SPI, Camera Interface (2x MIPI CSI) |
| Operating System | Windows® 8, Windows® 7, WE8S, WES7, WEC7, Linux, VxWorks |
| Power Supply | 3V – 5.25V Operates directly from single level Lithium Ion cells or fixed 3.3V or 5V power supplies |
| Power Consumption | tbd |
| Temperature | -40°C to +85°C operating, -40°C to +85°C non-operating |
| Humidity | 93% relative Humidity at 40°C, non-condensing (according to IEC 60068-2-78) |
VARIANTS
| SMARC-sXBTi E3845 4E/16GB 51004-4016-19-4 |
 |
SMARC with Intel® Atom E3845, 4×1.91GHz, 4GB DDR3L ECC memory down, 16GB SLC eMMC, industrial temperature | |
| SMARC-sXBTi E3825 2GB 51004-2000-13-2 |
|
SMARC with Intel® Atom E3825, 2×1.33GHz, 2GB DDR3L memory down, industrial temperature | |
| SMARC-sXBTi E3827 1E/4S 51004-1040-17-2 |
|
SMARC with Intel® Atom E3827, 2×1.75GHz, 1GB DDR3L ECC memory down, 4GB SLC eMMC, industrial temperature | |
| SMARC-sXBTi E3845 2GB 51004-2000-19-4 |
|
SMARC with Intel® Atom E3845, 4×1.91GHz, 2GB DDR3L memory down, Industrial temperature | |
| SMARC-sXBTi E3827 2GB 51004-2000-17-2 |
|
SMARC with Intel® Atom E3827, 2×1.75GHz, 2GB DDR3L memory down, industrial temperature | |
| SMARC-sXBTi E3826 2GB 51004-2000-15-2 |
|
SMARC with Intel® Atom E3826, 2×1.46GHz, 2GB DDR3L memory down, industrial temperature | |
| SMARC-sXBTi E3815 1GB 51004-1000-15-1 |
|
SMARC with Intel® Atom E3815, 1×1.46GHz, 1GB DDR3L memory down, industrial temperature |
ACCESSORIES
| SMARC Starterkit 51100-0000-00-S |
 |
The SMARC Starterkit with SMARC Eval Carrier is equipped for express evaluation purposes. | more |
| SMARC Mounting Kit 51117-0000-00-0 |
|
SMARC Mounting Kit | |
| HSP SMARC™-sXBTi 51004-0000-99-1 |
|
Heatspreader for SMARC™-sXBTi |
