Specifications |
Model | – JNU95-10210 |
Form Factor | – NUC (101 * 101mm) |
Processor System | – Intel® 10th Gen. Comet lake CoreTM MCP Processor, I5-10210U QC, 1.6GHz, 15W – SoC chipset – AMI 128M Flash ROM BIOS |
Expansion Slot | – 1* M.2 M key (2242, SATA interface) – 1* M.2 E key (2230, Support CNVi) – 1* SATAIII |
Memory | – 2* DDR4 2666 MHz SO-DIMM up to 64GB |
Graphics | – 1* HDMI1.4 (Max Resolution : 4096×2304@30Hz) – 1* HDMI2.0 (Max Resolution : 4096×2304@60Hz) – 1* DP (Max Resolution : 4096×2304@60Hz) – Support Triple Displays |
Ethernet | – 1* Intel® I219LM GbE – 1* Intel® i211AT GbE |
Audio | – HD Audio: Realtek® ALC662 |
SATA | – 1* SATAIII (6.0Gb/s) |
Rear I/O | – 2* HDMI – 1* DP – 2* RJ45 – 2* USB3.2 (Gen2) – 12~24V DC-in |
Front I/O | – 1* Audio (Line-out, MIC) – 1* RS232/422/485 (Support 5/12V TTL) – 2* USB3.2 (Gen2) |
Internal Connector | – 2* USB2.0 – 1* SATAIII (6.0Gb/s) – 1* M.2 (M key) – 1* M.2 (E key) – 1* GPIO (8bit, 5V) – 1* AT mode |
Watchdog Timer | – From Super I/O to drag RESETCON# – 256 segments (10 ~ 255min) |
Power | 12~24V DC-in, AT/ATX Supported – AT: Directly PWR on as Power input ready – ATX: Press Button to PWR on after Power input ready |
Compliance | – CE, FCC, RoHS, REACH |
Temperature | – Operating: 0°C ~ 60°C – Storage: -20°C ~ 85°C – Humidity: 10% ~ 90% RH @40°C (non-condensing) |
OS Support | – Windows 10, Linux |
Warranty | – 2 Years Limited Warranty |
* Specifications subject to change without notice, not responsible for typographical errors. Does not include HDD or OS.
Accessories |
Part Number | Description |
JNU95 M/B | |
G01-SATA3-BL-1F | STAT cable |
G01-PW4P4S-SAT-1F | Y-Power cable |
