| Specifications |
| Form Factor | |
| Dimensions | – 5.25” (120 * 200mm) |
| Processor System | |
| CPU | – INTEL® Celeron™ J1900 (2.0 GHz) quad-core processor |
| Core Number | – 4 |
| Max Speed | – 2.0GHz |
| L2 Cache | – 2MB |
| Chipset | – SOC |
| BIOS | – AMI 64Mb Flash ROM |
| Expansion Slot | |
| PCI | – 0 |
| Mini-PCIe | – 1 (full size) |
| M.2 | – 1(2242/2260/2280) |
| SIM card holder | – 1 |
| Memory | |
| Technology | – Onboard SAMSUNG 4G/1333MHz DDR3L Memory |
| Max. | – 8GB |
| Socket | – 0 |
| Graphics | |
| Controller | – (by CPU) |
| VRAM | – Shared Memory |
| VGA | – 1 (Max. Resolution: 1920×1200@60Hz) |
| LVDS | – 1 (Max. Resolution: 1920×1200@60Hz) |
| eDP | – 1 (Max. Resolution: 2560×1600@60Hz) |
| HDMI | – 0 |
| DVI‐D | – 0 |
| MultiDisplay | – Yes (Dual Displays) |
| Ethernet | |
| Ethernet | – 10/100/1000 Mbps |
| Controller | – 2 * Intel® i211AT Gigabit LAN |
| Connector | – 2 * RJ 45 |
| Audio | |
| CODEC | – HD Audio : Realtek ALC662 |
| Channel | – 2 Channe |
| SATA | |
| Max Data Transfer Rate | – 1 * SATAIII (6.0Gb/s) |
| Rear I/O | |
| VGA | – 1 |
| DVI-D | – 0 |
| Display Port | – 0 |
| Ethernet | – 2 |
| USB | – 4 (2 * USB3.0 + 2*USB2.0) |
| Audio | – 0 |
| Serial | – 2 (RS-232/422/485 with 5V/12V selectable header) |
| DC-input | – 1 |
| Internal Connector | |
| USB | – 2 ( 2 * USB 2.0 ) |
| PS/2 | – 0 |
| LVDS / inverter | – 1 |
| eDP | – 1 |
| Serial | – 2 (2 * RS-232 with 5V/12V selectable header) |
| SATA | – 1 * SATAIII (6.0Gb/s) |
| Mini PCI-e | – 1 (full size) |
| M.2 | – 1 (2242/2260/2280) |
| GPIO | – 4 in / 4 out |
| Chassis intrusion | – 1 |
| Audio Header | – 1 |
| SMBUS/ I2C | – 1/1 |
| AT mode | – 1 |
| Others | – Support Expansion card (2*COM+2*USB2.0) |
| Watchdog Timer | |
| Output | – From Super I/O to drag RESETCON# |
| Interval | – 256 segments, 0,1,2…255sec/min |
| Power Requirements | |
| Input PWR | – +9~28V DC-in (2-pin PWR Con) |
| Power On | AT/ATX Supported – AT : Directly PWR on as Power input ready – ATX: Press Button to PWR on after Power input ready |
| Certifications | |
| Certifications | – CE, FCC, RoHS, REACH |
| Environment | |
| Temperature | – Operating: 0°C ~ 60°C |
| – Storage: -20°C ~ 85°C | |
| Warranty | |
| Warranty | – 2 Years Limited Warranty |
* Specifications subject to change without notice, not responsible for typographical errors. Does not include HDD or OS.
| Accessories |
| Part Number | Description |
| JNC7A-E1900-4G M/B | |
| G01-COM-H2M22-1F | COM cable |
